The M2X10A Dual-Channel Motor Driver is a robust and high-power motor driver designed as a direct replacement and upgrade for the TB6612FNG. Capable of handling up to 30V and delivering 13A continuous (80A pulsed T < 10us ) per channel, this driver is perfect for demanding applications like combat robots, sumo robots, and high-power actuators.
PWM and direction control, slow decay braking, and a standby mode to reduce power consumption when not in use. The driver operates from a 1.8V-5.5V logic level, making it compatible with a wide range of microcontrollers, including Arduino, STM32, and Raspberry Pi.
Unlike the TB6612FNG, the M2X10A does not limit output current, allowing full control over motor performance. However, thermal management must be considered, as heat dissipation increases with load. For best results, all GND pins should be connected to improve thermal performance.
With its compact size, high efficiency, and improved power handling, the M2X10A is an excellent choice for advanced projects.
Size: 21.2mm x 21.2mm
Weight: 2.1g
Includes: 1pcs M2X10A Motor Driver
Product datasheet: SoBotz M2X10A Motor Driver Datasheet
3D files: GrabCad
